Product 1 :
Pocket Switch
Control electrical appliances (like light, fan, AC) anywhere from the world using android app & remote control!
Description
- > Home automation SIM card enabled smart device, no need of existing WiFi connection
- > One activated SIM card required (Airtel/Docomo/Vodafone)
- > Supported mobile operating system – Android 7.0 Nougat to any upper Android versions
- > Controllable home appliances – Direct connection with smart box of all electrical appliances under 220 Watt, in case of AC, Refrigerator, pump, and Geyser will be connected via another small electrical parts relay
- > Input / Output Voltage: AC 150-250V
- > Smart BOX Operating Voltage: DC 12V 2Amp power adapter (Included with package)
- > Infrared remote which used for operate light from your room only (included with package)
- > Battery required for remote only (included with package)
- > No extra components required, any electrician can directly installed it to any existing switch board
Features
- > It is made in India, and not a counterfeit. So after warranty period if there is some issue, smart device will be repaired by company
- > Easy installation, easy handling and can be activated immediately
- > WiFi connection or any router not required. So anyone can use it without any hesitation
- > Android app is available in google play store
- > One single Android app can handle multiple smart devices of different room, or different building at a time
- > Multiple Android mobile can handle one single smart device, like access by different family members
- > Only selected android mobile set can access the smart device. Selection may changes at any time
- > When operate using Android app, the same status will reflect to the smart box within 5-10 seconds (If the network condition is good in your mobile and in smart box)
- > When operate using infrared remote unit, the same status will reflect to the smart box immediately, and reflect in Android app with 1-5 seconds (If the network condition is good in your mobile and in smart box)
- > Control un-smart electrical devices from anywhere through mobile internet using android app
- > Scheduled timer for ON and OFF for individual applications whenever you want in a day
- > Control fan speed with a wide range of speed point (1-LOW 9-HIGH) from app and also from remote
- > 1 year limited warranty on the smart device (12v DC 2Amp power adapter, infrared remote will not include)
How to install
Download app from google Play store
Product 2 :
Microcontroller Based Automatic Water Tank Monitoring System
Solution for overhead and base tank water monitoring and operate the pump automatically!
Application:
- > When overhead tank is below half, it turns ON pump automatically.
- > When overhead tank is full, it turns OFF pump automatically.
- > When no water in reservoir tank, the pump stops and protects from dry run.
Advantages:
- > No tension of turning pump ON/OFF.
- > No tension of checking water level in the reservoir tank.
- > Overhead tank is always - half to full, of water.
- > No water wastage; no power wastage.
- > Five levels of water level indicator – 20%, 40%, 60%, 80% & 100% of water
- > LED notification for:
- > Pump running status.
- > Reservoir tank insufficient water.
- > Dry run protection.
Salient Features:
- > Magnetic Float Sensors works with water; irrespective of water characteristics, detects water level.
- > No salt formation, corrosion, etc. on sensors.
- > Manual switch to turn ON/OFF pump.
- > System will install in existing pump board.
- > Very minimal maintenance required, when necessary.
- > No schedule maintenance required.
- > Detects frequent power cut condition and protects pump from frequent start and stop.
- > Detects power cut condition and runs pump when power is return, if required.
- > Shows heartbeat for notifying the working state.
Product 3 :
Microcontroller Based Wireless Electrical Switch Board
Smart IoT based solution for making the electrical switch board wireless at home, office, conference room using an android app!
Application:
- > Access and control any electrical appliances like light, fan using android phone and IR remote.
- > Schedule switch ON and switch OFF timers at any appliances.
- > Multiple android phone users (max 10 persons) can access the same board.
- > Multiple smart boards can access from single app - Pocket Switch BT.
- > Fan regulation speed also controlled from android app.
Advantages:
- > No tension of switching the appliance ON or OFF from the physical board.
- > Fully controllable from android phone and IR remote.
- > Wide range of distance covered from your phone to the Smart board.
- > No internet required, no minimum balance required, and no network required in your phone.
- > Max 10 android phone users can access a single Smart board.
- > Only registered android phone users can operate the board.
- > Max 50 timers can be set for different appliances as per user choice.
- > Facility to set auto increment and auto decrement fan speed timers.
- > Completely free android app founds in Google Play Store, named Pocket Switch BT.
Salient Features:
- > Easily convert your Old Unsmart light, fan to Smart light, and fan without throwing or replacing them.
- > Easily installed with any physical switch board, just need an electrician.
- > Timers are automatically adjusted and do their job even on power failure.
- > Smart board timers are easily editable at any time.
- > Registered android users can edit the permission of other android users.
- > No need to contact anyone for registration or deregistration of android phone.
- > Access any electrical switch from your entire room without touching the physical switch.
- > User can maintain their switch names, registered user names, also Smart board names from android app.
How to install
Download app from google Play store
Product 4 :
Microcontroller Based GSM SIM Enabled Pump Monitoring & Security System
Solution for monitoring and operate a pump from anywhere with a basic keypad phone!
Application:
- > Automatic and unattended pump monitoring and security system.
- > Applicable, where no limits of reservoir or ground water, and not used for filling water to tank.
- > Turns ON the pump by just one missed call or SMS.
- > Turns OFF the pump by one missed call or SMS, or it will automatically stop with timer.
Advantages:
- > No tension of turning pump ON and OFF from the actual physical location.
- > Fully operable from any remote location.
- > GSM SIM card enabled controller, operated through missed call and SMS.
- > Wide range of network support.
- > Operated by Vodafone, DOCOMO, !dea, BSNL SIM cards
- > No smart phone, no internet required, controlled by one old fashion keypad phone.
- > Need minimum balance for SMS and incoming call facility in the installed SIM card.
- > 5 phone numbers can registered in this system.
- > Only registered persons (with registered mob no) can operate the system.
- > At the very beginning, first person registration will be done by just a phone call.
- > Remaining 4 persons will be registered via SMS from registered person.
- > Registration modification possible at later time.
- > Set timer from 1 minute to 12 hours.
- > Cancel any running timer.
- > Manual switch to turn ON/OFF pump.
Salient Features:
- > Check pump running status, SIM signal status and registered persons list.
- > Individual SMS notification of every single action with very strong security.
- > Store last information about who starts and stops the pump and the duration.
- > LED notification for GSM device problem, SIM card not properly inserted, invalid SIM card registration failed, user registration checking and low balance.
- > Shows heartbeat for notifying the working state.
Product 5 :
Microcontroller Based Water Tank Monitoring & Alarming System
Smart solution for monitoring overhead and reservoir water tank where several separate tanks are maintains with a single pump
Youtube Video Demo
Application:
- > When overhead tank is below 40%, it turns ON alarm for overhead tank empty or underflow.
- > When overhead tank is full (100%), it turns ON alarm for overhead tank full or overflow.
- > When no water in reservoir tank, it turns ON alarm for reservoir tank empty.
Advantages:
- > Don't worry about running out of water in the tanks behind your eyes.
- > No chance of overflowing and wastage of water from overhead tank.
- > Maintains all tanks water level with audio and visual monitoring system.
- > Once the water is full or below normal, it can be heard with the help of different beautiful music. So you don't have to stand until the water is full or below normal.
- > If the water level of overhead tank founds as below normal, system will notify it with audible alert after every 30 seconds.
- > If the reservoir tank has insufficient water, system will notify it with audible alert after every 60 seconds.
- > If the overhead tank is filled with water or overflowing, system will notify it with audible alert continuously.
- > You can stop any running audible alert by pressing stop switch. Otherwise system will automatically make it stop at a proper time.
- > If the audible alert is already activated, no need to turn ON or turn OFF any other switch every time for getting overflow and underflow alert from tanks.
- > No water wastage so obviously no power wastage.
- > Five levels water level indicator – 20%, 40%, 60%, 80% & 100% of water.
- > LED notification for reservoir tank insufficient water.
- > Reservoir tank empty alarm protects the pump from dry run.
Salient Features:
- > Sensors works with water; irrespective of water characteristics, detects water level.
- > No salt formation, corrosion, etc. on sensors.
- > Manual switch to activate or deactivate the audible alert system.
- > Manual switch to stop the buzzer for that cycle.
- > Very minimal maintenance required, when necessary.
- > No scheduled maintenance required.
- > Shows heartbeat for notifying the working state.
